For customers using Adapt9S12DP256/512, we've created a small circuit board to transform your module into the equivalent of a MicroBDM12SX pod. It includes a connector that fits over the section of pins on H1 that DBug12 uses to implement BDM OUT functionality. Just plug it onto the matching section of H1, and plug the included 10-pin ribbon cable into your HC12 target board. Order #BDM256XFMR-. Choose the appropriate connector option () to mate with H1 on your Adapt9S12DP256, as follows:

• choose "F" if your module's H1 connector is RA1, M, or FM
• choose "F1" if your module's H1 connector is RA, M1, or FM1
• choose "M" if your module's H1 connector is FRA, F (or FM)
• choose "M1" if your module's H1 connector is FRA1, F1 (or FM1)
